6×15 m Arched Hall 205012P

205012P
€3,299.75 tax excl.
€4,058.69 tax incl.
Delivery within 3-4 days
Follow our tips for purchasing and installing this product:
phone +48 604 108 143
email [email protected]
Monday - Friday 8.30 - 17.30

Compact arched halls.

Arched halls measuring 6 m in width and length are an extremely practical, versatile and durable solution for agriculture, industry and all types of warehousing operations. Thanks to their distinctive arched design, they offer exceptional resistance to harsh weather conditions, ensuring reliability in all circumstances.

Our arched tent halls are made from durable materials: thick 900g/sq m PVC tarpaulin and galvanised steel profiles. They are an excellent alternative to traditional brick-built structures, offering mobility and flexibility of use. The lightweight yet robust construction makes arched halls an extremely cost-effective solution. More and more farmers are opting for this product, recognising its functionality.

Colour

No carriers available for this product.


Data sheet Specification
Tearing strength of PVC tarpaulins EN ISO 13934-1 3600N (360 Kg)
UV protection: 50+ according to EN 13758-1:2007 YES
Thickness of PVC tarpaulin 900 g/m2
Width (m) 6.10
Length (m) 15.25
Door opening width (m) 4.30x3.20
Height (m) 3.60
Curve interval (m) 1,525
1.50
Arc Φ (mm) 70.0 x 42.0 x 1.50
Purlin Φ (mm) 40.0 x 1.20
Snow load (kPa) 0.28
Maximum wind speed (wind load) (km/h) 80
Number of entrance gates 2

Specific References

EAN13
5901783470323

Arched halls are always in stock.

Experience shows that it is often necessary to react quickly to changing circumstances. That is why, to meet our customers’ needs, we fulfil orders without delay. We always have several arched halls in stock, which allows for rapid dispatch. Within Poland, we deliver goods within 2 days, and within Europe within 2–4 days.

Our standard range includes tarpaulins in white and green. We also offer other colours to order.

A sturdy structure is an investment for years to come

The galvanised steel tubes used to construct the frame of the arched tent hall are corrosion-resistant, guaranteeing durability for many years. The entire structure is covered with the thickest PVC tarpaulin on the market ( 900 g/m²), which provides excellent protection against the elements. The tarpaulin is waterproof and UV-resistant, ensuring that goods, equipment, bales of hay or machinery stored inside the tented warehouse are fully protected against rain, wind, snow and the harmful effects of the sun.

Wide doors located on the gable walls ensure adequate ventilation, which is particularly important when storing hay or straw.

Key features of the 6-metre-wide arched hall

The 6-metre-wide arched hall is available in a range of lengths: 6, 9, 12, 15, 18, 20 and 24 metres. Thanks to its modular design, it can be extended as required to suit your needs.

- Structure – the arched roof shape effectively drains rainwater and snow, minimising the load on the structure.
- Tarpaulin colour – the standard colours for the tarpaulin are white and green. White allows sunlight to pass through, meaning no additional lighting is required during the day. The green tarpaulin of the arched halls blends in with the rural surroundings.
- Quick assembly and dismantling – Arched halls are renowned for their quick assembly. A 6-metre-wide arched hall can be assembled by three people in a single day, without the need for specialist tools.
- Mobility – unlike traditional buildings, arched halls can be easily moved to another location. The mobility of this type of structure is extremely important in agriculture or the industrial sector, where needs may vary seasonally or depending on location.
- Flexibility: Once it is no longer needed, the hall can be dismantled, packed into a crate and sold, offering additional opportunities for space and resource management.

Applications for a 6-metre-wide arched hall of various lengths

Over many years of selling storage halls and storage tents, products with an arched roof shape are most commonly chosen by:

- Agriculture – Arched halls are ideal for storing bales of hay, straw, fodder, grain, fertilisers and agricultural machinery. Thanks to their design, they ensure the safe storage of crops, protecting them from damp and harsh weather conditions.

- Warehousing – In warehousing operations, arched halls serve as additional space for goods, tools, equipment and raw materials. They are particularly valued in sectors such as coal, timber and aggregate storage, as well as waste sorting facilities.






For more information or inquiries, please visit our contact or our customisation page.
